wavedrom

:ocean: Digital timing diagram rendering engine

Runssource: GitHubhomepageJavaScriptMITcommit 142dd41870bc

JavaScript, MIT licensed. The project labels itself: diagram, hacktoberfest and svg.

wavedrom runs. An Argusic agent installed it in 2.5 minutes and hit 1 error and fixed every one without help on a clean machine with no GPU, and the whole session was recorded.

WaveDrom 3.7.0 builds and runs with Node 20; CLI accepts --input/--indent/--version/--help and generates SVG from JSON5 files; all 6 mocha tests pass; 4 browser bundles (wavedrom.js, wavedrom.min.js, wavedrom.unpkg.js, wavedrom.unpkg.min.js) built successfully; no third-party credentials required.

What the agent ended up with on a clean machine, in its own words. How this is measured

Measured by Argusic on a fresh machine every time. Every number links to its evidence. Argusic Score 100 of 100 (the mean of this project's run scores).
