nomnoml

The sassy UML diagram renderer

Runssource: GitHubhomepageTypeScriptMITcommit 3f30d38556e9

TypeScript, MIT licensed. The project labels itself: class diagram, diagram, flowchart, nomnoml and uml.

nomnoml runs. An Argusic agent installed it in 0.1 minutes and hit no errors on a clean machine with no GPU, and the whole session was recorded.

nomnoml v1.7.0 installed, built, and tested: all 132 unit tests pass, the library API (renderSvg) returns valid SVG, the CLI tool generates SVG files from .noml input, and the webapp bundle is built

What the agent ended up with on a clean machine, in its own words. How this is measured

Measured by Argusic on a fresh machine every time. Every number links to its evidence. Argusic Score 100 of 100 (the mean of this project's run scores).

At a glance

verdict
Runs
Argusic Score
100 / 100
cost of the verifying run
$0.01 (measured)
recorded runs
2
last tested
stars
2,840
forks
210
open issues
16
watchers
39
size
1 MB
created
last push

Subject data from GitHub, linked at the top of this page, refreshed . Test data by Argusic (CC BY 4.0); every number links to a run page with the full log, the recording, and their sha256 hashes.

What was measured

From the run that decided this verdict. Every line is a recorded value, not an estimate.

Install time
under a minute
Cold machine to finish
1 minutes
Errors hit and fixed
0 hit, 0 fixed with no human help
How the result was proved
npm test exited 0 (132 passed, 0 failed); CLI 'node dist/nomnoml-cli.js test/import-test.nomnoml test/output.svg' produced valid SVG; 'node -e "nomnoml.renderSvg('[test] -> [works]')"' returned valid SVG with expected content
Model tokens used
40,477
Exact commit tested
3f30d38556e9
Container image
sha256:cdd920bce783

What was not measured

The other half, so you can see exactly how far this evidence goes. A gap is printed as a gap and never filled in.

Peak GPU memory
this ran on a CPU machine, so there was no GPU to sample
Behaviour over a long run
each attempt uses the smallest documented settings and a fixed time budget, so this measures whether it runs, not how it holds up under load

The end of the recording

The last lines of the terminal session that decided this verdict, exactly as they were recorded.

  \"install_minutes\": 0.15,
  \"errors\": [],
  \"test_depth\": \"tier1_real\",
  \"notes\": \"No third-party keys required. All 132 tests pass. SVG output validated for well-form…
  \"verified_how\": \"npm test exited 0 (132 passed, 0 failed); CLI 'node dist/nomnoml-cli.js test/…
  \"final_state\": \"nomnoml v1.7.0 installed, built, and tested: all 132 unit tests pass, the libr…
}
EOF" in /work/repo
 succeeded in 0ms:
{"install_succeeded": true, "launch_succeeded": true, "install_minutes": 0.15, "errors": [], "test_…
tokens used
40,477

Replay the whole session, every command from a clean machine to this point.

How it was tested

One agent, one container, no human help. It installs the project the way its own documentation says to, runs it, and fixes what breaks. Everything below is recorded as it happened: the terminal session, the log and the exact commit. The full method.

Strengths and limits

Measured facts, not opinions. How this is written.

What went well

  • Reached a running state on a clean machine, with the session recorded.
  • Installed in 0.1 minutes.
  • Nothing broke on the way: zero errors between clone and running.
  • Ran without a GPU, so it does not need one to start.
  • Licensed MIT, as reported by its host.
  • Measured 2 times, so the result is not a one-off.

What it is a reasonable choice for

  • Trying it on a laptop or a small server: it reached a running state without a GPU.
  • A quick evaluation: it was running 0.1 minutes after the clone.
  • Following its own README: the documented path worked with nothing to fix.

Also tested, in the same area

Every one of these was installed and run by Argusic on a clean machine. Nothing appears here that was not tested.

Run history

tested byattemptoutcomescorecost USDwhen
Argusic Runner2/3Runs100.000.01
Argusic Runner1/3Runs100.000.01

Topics (from GitHub)

class-diagramdiagramflowchartnomnomluml

Embed the badge

Markdown for the project README. It links back here; terms on the terms page.

[![Tested by Argusic](https://argusic.com/badge/nomnoml.svg)](https://argusic.com/subject/nomnoml)

Questions

Does nomnoml run?
Yes. nomnoml runs. Argusic installed and launched it on a clean machine in 0 minutes, hitting 0 errors on the way, and recorded the session.
How did Argusic test nomnoml?
On a fresh, disposable machine, with every command recorded and the repository pinned at commit 3f30d38556e9. 2 attempts are recorded, and the full method is on the methodology page.
What did it cost to test nomnoml?
The run that produced this verdict cost $0.01: real compute and model cost, not a list price per million tokens. It is recorded on that run's page.
How long does nomnoml take to install?
0.1 minutes in the run that decided this verdict, from a clean machine to a running state. That is one measured attempt, not an average.
Does nomnoml need a GPU?
Not to start. Argusic reached a running state on a machine with no GPU.
What goes wrong when installing nomnoml?
Nothing did, in the recorded run: zero errors between clone and running.
Where is the evidence for nomnoml?
All 2 recorded runs are on this page, each linking to its full log and terminal recording, stored with a sha256 fingerprint so it cannot be quietly altered.
